Display Type: Single-chip DLP;
Resolution: WUXGA (1920 × 1200);
Light Source: Red and blue dual-color laser;
Brightness: 16,000 lumens;
Uniformity: 90%;
Contrast Ratio: 3,000,000:1 (fully on/off);
Light Source Life: 20,000 hours (normal mode)/30,000 hours (Energy-saving mode)
Lens Type: Electric Lens;
Zoom ratio: Lens Model;
Projection Ratio: T/R 0.31~0.33、T/R 0.55~0.75、T/R 0.74 - 1.08、T/R 1.05 -1.41、T/R 1.4- 2.11（标准镜头）、T/R 2.1-4.0、T/R 3.0-4.52 、 T/R 4.46 -6.94;
Camera displacement-Horizontal: Maximum +20% to-20%;
Camera displacement-Vertical: Maximum +60% to-60%;
Trapezium Correction: Supported;
Quadrant Correction: Supported;
I/O:HDMI:2.0 x2
DisplayPort:1.2 x2
SDI:3G-SDI In x1 / Out x1
DVI-D:x1
3D Sync:3D SYNC IR x1 / SYNC In x1 / SYNC Out x1
RJ45:HDBaseT x1, LAN x1
RS-232:In x1 / Out x1
Wire Remote:In x1 / Out x1
USB:Type A*1 (Power Only 5V/2A) x1
12V Trigger (mini Jack):x1 ;
Power Supply: AC 100–240 V, 50/60 Hz;
Power Consumption: 900 W;
Standby Power: <0.5 W / <3.0 W (network standby);
Noise Level: Standard: 39 dB; Energy-efficient Mode: 36 dB;
Dimensions: 500 × 591 × 218 mm; Weight: 29.4 kg;
Operating Environment: Temperature 0–40 °C, Relative Humidity 10–85%; No condensation
Storage Environment: Temperature-20–60 °C, Relative Humidity 10–95%.No condensation
